Ysra 32-60 Industrial Shock Absorbers



 🛠️ Fixed Hydraulic Shock Absorber – Model YSRA-32-60-C

The YSR-32-60-C is a compact, high-efficiency fixed hydraulic shock absorber designed for industrial automation, rotary actuators, and linear motion systems. Manufactured by Festo, it features a galvanized steel body, high-alloy chrome-plated piston rod, and self-adjusting damping for consistent energy absorption across a wide range of impact conditions.

⚙️ Technical Specifications ParameterValue

Stroke Length	60 mm
Max. Energy per Cycle	380 J
Max. Energy per Hour	220,000 J
Max. Stop Force	6,000 N
Impact Velocity	Up to 3.0 m/s
Reset Time	0.5 s (room temp), 1 s (low temp)
Reset Force	20 N
Min. Insertion Force	160 N
Load Range	Up to 400 kg
Body Material	Galvanized steel
Rod Material	Hardened high-alloy steel, chrome plated
Mounting	Lock nut
Operating Temperature	–10°C to +80°C
Weight	~1220 g
Corrosion Resistance Class	CRC 2 (moderate stress)
Compliance	RoHS, VDMA24364-B2-L (PWIS conformity)

✅ Features

• Fixed damping with self-adjusting internal throttle
• Compact design for space-constrained installations
• Rapid reset time for high-cycle operations
• High corrosion resistance for industrial environments
• No external adjustment required – ideal for standardized setups
• RoHS compliant and suitable for cleanroom applications

🏭 Applications

• Pneumatic actuators
• Rotary indexing tables
• Linear slides and pick-and-place systems
• Packaging and printing machines
• Compact automation modules
