AKHG6550 EOT Crane Hydraulic Shock Absorbers

Link Copied
16,800.00 / Piece( + 18% GST applicable)

10 Piece (MOQ)

Business Type Manufacturer, Exporter, Supplier
Application Overhead Cranes
Type Crane Rail
Material Metal, Cast Iron
Click to view more

Product Details

Brand Name
ADONI TECH
Shape
Round
Color
YELLOW
Energy Capacity Per stroke
4000 NM
Stroke
50MM
RETURN PRESSURE
10 BAR MIN
Product Code
AKHG6550
Port
MUBAI
Payment Terms
T/T

 🛠️ Hydraulic Buffer – Model AKHG65-50

The AKHG65-50 hydraulic buffer is a compact, high-performance energy absorption device designed for industrial and heavy-duty applications. Engineered by KOBA, it features a self-adjusting damping system, hard chrome-plated piston rod, and epoxy-coated body, ensuring reliable performance across demanding environments.

⚙️ Technical Specifications ParameterValue
Stroke Length 50 mm
Max. Energy per Cycle 4 kJ
Max. Buffer Force 100 kN
Return Mechanism Nitrogen gas
Filling Medium Oil + Nitrogen gas
Operating Temperature –10°C to +80°C (Standard), –40°C to +120°C (Special)
Piston Rod Hard chrome plated (≥25 µm)
Body Finish Epoxy paint coating
Mounting Options Rear flange (RS), front flange (FS), clevis, or custom
Weight ~3.5–4.7 kg
✅ Features
  • Self-adjusting damping for consistent deceleration across variable impact speeds
  • Multiple orifice design tailored to application-specific energy profiles
  • Compact and rugged construction for space-constrained installations
  • Corrosion-resistant epoxy finish for long-term durability
  • Global compliance: OSHA, AISE, CMMA, DIN, FEM standards
🏭 Applications
  • Container cranes
  • Overhead and stacker cranes
  • Transfer cars
  • Rail systems
  • Steel plant safety zones
  • Amusement rides
  • Defense-grade mobile platforms
