Crane Rail EI 80 X 100 Hydraulic Buffer for Overhead Cranes

Link Copied
33,000.00 / Piece( + 18% GST applicable)

10 Piece (MOQ)

Business Type Manufacturer, Exporter, Supplier
Application Overhead Cranes
Type Crane Rail
Feature Easy To Use
Click to view more

Product Details

Color
Silver
Model Number
EI 80 x 100
Stroke
100mm
Energy Capacity Per stroke
15600NM
Payment Terms
D/P, T/T



🛠️ Hydraulic Buffer – Model EI 80 × 100 / AKHG 80-100

The EI 80 × 100 hydraulic buffer is a medium-duty energy absorption device designed for overhead cranes, transfer cars, and industrial safety systems. Featuring a Yellow epoxy-coated body, Arkor-finished hardened chrome-plated piston rod, and a PU stroker cap, it ensures long-term corrosion resistance and consistent damping performance in harsh environments.

⚙️ Technical Specifications ParameterValue
Stroke Length 100 mm
Max. Energy per Cycle 15.6 kJ
Max. Buffer Force 160 kN
Return Mechanism Nitrogen gas
Filling Medium Oil + Nitrogen gas
Rod Finish Hardened chrome plated with Arkor coating
Body Finish Yellow epoxy paint
Cap Material Polyurethane (PU)
Mounting Options Front flange (FF), Rear flange (FR), or custom
Weight ~22 kg
Operating Temperature –10°C to +80°C (Standard), –35°C to +100°C (Optional)
✅ Features
  • Self-adjusting damping for consistent deceleration across variable impact speeds
  • Multi-orifice design tailored to application-specific energy profiles
  • Arkor rod finish for enhanced corrosion resistance in coastal or chemical environments
  • PU stroker cap for quiet operation and smooth reset
  • Compact and rugged construction for space-constrained installations
  • Global compliance: OSHA, AISE, CMMA, DIN, FEM standards
🏭 Applications
  • Overhead and gantry cranes
  • Transfer cars and rail systems
  • Steel plant safety zones
  • Amusement rides
  • Defense-grade mobile platforms
  • Port and container handling systems
